Structural composition of injection molds and solutions to rust

Table of Contents


Injection molding is a cornerstone of manufacturing in various industries, from automotive parts and electronics to consumer goods. This versatile process allows for the production of complex and precise plastic parts at scale. However, the success of injection molding hinges not only on expertise but also on the reliability and durability of injection molds.

One of the most significant challenges that injection mold operators encounter is the insidious issue of rust. The structural integrity of injection molds can be compromised when rust takes hold, leading to a cascade of quality problems, affecting product quality and production efficiency. In this article, we will delve into the world of injection molds, exploring their vital role in various industries and shedding light on the persistent challenge of rust that manufacturers must address to ensure smooth operations and high-quality products.

II. Understanding the Structural Composition of Injection Molds

1. Molded parts

Parts that give shape, structure, and dimension to molding material typically consist of cores, concave mold cavities, threaded cores, and inserts.

2. Gating system

It usually consists of a main channel, a runner, a gate and a cold well. It is a channel that guides molten plastic from the injection machine nozzle to the closed cavity.

3. Guide parts

Some molds also have guides on the ejector plate, which are composed of guide posts and guide bushes to ensure smooth and reliable movement of the demoulding mechanism. In order to ensure that the movable mold and the fixed mold can be accurately aligned when closed, the guides play a guiding and positioning role.

4. Release mechanism

The most common phenomenon commonly used demoulding mechanism generally consists of an ejector pin, a reset rod, a slingshot, an ejector fixed plate, a top plate, a top guide post and a guide sleeve. There are various structural forms of demoulding devices for plastic parts and pouring systems.

5. Core pulling mechanism

Side core pulling or slider separation must be performed. For plastic parts with side holes or side concavities, they can be successfully demoulded before ejection.

6. Mold temperature adjustment system

There is a mold temperature adjustment system to adjust the mold temperature in order to meet the mold temperature requirements of the injection molding process.

7. Exhaust system

In order to smoothly discharge the produce volatile gases in the mold cavity, the parting surface of the mold is often equipped with an exhaust groove, and the push rod gap of many molds can also play the role of exhaust.

III. The Challenge of Rust in Injection Molds

Injection molding relies heavily on precision and quality to produce plastic parts that meet industry standards. However, a pervasive and formidable adversary often plagues the world of plastic injection molding: mold rust. In this section, we will delve into the reasons why mold rust poses a significant concern in injection molding, explain the mechanisms behind its formation, and address common questions regarding its impact.

Why Mold Rust is a Concern in Injection Molding

Mold rust is a pressing concern for several reasons:

  1. Affects Product Quality: Rust on the mold’s surface can directly transfer to the molded plastic parts, leading to defects and imperfections in the final product. These defects may include pinholes, blemishes, and irregularities that compromise the overall quality and appearance of the plastic parts.
  2. Increased Maintenance Costs: The presence of rust necessitates frequent mold maintenance and cleaning, driving up operational costs. Mold maintenance is not only time-consuming but also requires skilled labor and resources, making it a significant expense for manufacturers.
  3. Reduced Mold Lifespan: Rust can corrode and weaken the mold steel or other materials, thereby reducing the overall lifespan of the mold. This can result in the need for premature mold replacement, further increasing production costs.
  4. Production Downtime: When rust-related issues arise, production lines may need to be temporarily halted for mold maintenance and rust removal. This downtime can disrupt production schedules and impact overall efficiency.

How Rust Forms on Injection Molds

Rust formation on injection molds is a complex process influenced by various factors:

  • Moisture: Moisture in the air and condensation on the mold’s surface can provide the necessary conditions for rust formation. Water droplets that form on the mold can be particularly problematic.
  • Corrosive Gases: Some environments may contain corrosive gases that can accelerate rust formation. These gases interact with the mold’s surface and contribute to corrosion.
  • Downtime: When molds are temporarily stopped during production, they can be exposed to more moisture in the form of condensation, increasing the risk of rust.

IV. Solutions to Prevent and Address Rust

Addressing rust in injection molds requires a proactive approach, incorporating various strategies to solve the problem, prevent its formation and mitigate its effects. Let’s explore practical solutions to prevent and address rust on injection molds:

Material Selection

Material Selection plays a crucial role in rust prevention. Choosing corrosion-resistant plastic materials, for your plastic molds, such plastic material such as mold steel or corrosion-resistant alloys, significantly reduces the likelihood of rust formation. These materials can withstand exposure to moisture and corrosive gases, ensuring the longevity and durability of the molds.

Regular Maintenance

Implementing a Regular Maintenance schedule is essential for keeping rust at bay. Routine maintenance includes tasks such as cleaning the mold’s surface using a soft cloth, lubricating movable parts to prevent friction-induced corrosion, and thorough inspections to identify and address any signs of rust or potential corrosion points. Regular maintenance not only extends the molding material’s lifespan but also ensures consistent product quality.

Surface Treatments

Surface Treatments like chrome plated can be highly effective in preventing rust on injection molds. Chrome plating treatment a protective layer on the mold’s surface, acting as a barrier against moisture and corrosive agents. This treatment enhances the mold’s resistance to rust and corrosion, making it an invaluable investment for long-term injection mold and durability.

Controlled Environment

Maintaining a Controlled Environment in which molds are stored and operated can significantly reduce the risk of rust formation. Controlling humidity levels in the storage area minimizes moisture exposure. Mold rust often occurs when water droplets form on the mold’s surface due to high humidity. By creating a controlled environment, you can mitigate this risk.

Rust Inhibitors

Utilizing anti rust agentis another effective measure. These substances are specially formulated to protect molds from the corrosive effects of moisture cooling water, and corrosive gases. Rust inhibitors prevent the formation of carbides and inhibit the decomposition of mold materials, helping to keep rust at bay.

Mold Design

Mold Design can also play a role in rust prevention. Optimizing the mold design to prevent the accumulation of moisture in deep parts of the plastic mold, is essential. Ensuring that the surface of the mold is designed to minimize areas where water can collect can significantly reduce the risk of rust formation.

By incorporating these practical solutions into your injection molding processes, you can proactively prevent and address rust-related challenges. Ensuring that your molds are made from corrosion-resistant materials, implementing regular maintenance routines, applying surface treatments, maintaining a controlled environment during mold works, using rust inhibitors, and optimizing mold design are all key steps in safeguarding the longevity and performance of your injection molds.

In the next section, we’ll conclude our discussion on the structural composition of injection molds and the importance of rust prevention in the production of high-quality plastic parts.

V. Conclusion

In the journey through the structural composition of injection molds and the persistent challenge of rust, we’ve uncovered vital insights into the world of injection molding.

In conclusion, the structural composition of injection molds is a critical aspect of the injection molding process. Understanding this composition and the challenges posed by mold rust equips manufacturers with the knowledge needed to ensure the longevity and quality of plastic raw materials in their molds. By addressing rust-related issues through diligent maintenance and preventive measures, manufacturers can not only produce high-quality plastic parts but also improve cost-effectiveness and operational efficiency. Investing in the well-being of injection molds is an investment in the success of your manufacturing endeavors.
